Rebar Modelling & Detailing Services Project Title: Manawatu Tararua Highway BR02 Client : HEB Construction Project Description : A Tauranga highway Bridge constructing over a Manawatū River. It is a 4 span balanced cantilever bridge with variable superstructure. The length of the bridge is 300m long by 26.2m wide. Silicon is closely working on rebar modelling for Superstructure which includes Piers, deck slabs, abutments on Revit 3D. Location : Manawatu Tararua Highway BR02New Zealand Click here to View Project Drawings
Rebar Modelling & Detailing Service Project Title: BR03 – Eco Bridge Client: Fulton Hogan Project Title: The Te Ahu Turanga: Manawatu tararua highway, four lane eco bridge building on the northern side of the Manuwatu river. Silicon modelled the concrete pierhead in the Revit 3D and produced BBS, clash detection, clash resolves and co-ordination with the client. Location : BR03 – Eco BridgeNew Zealand Click here to View Project Drawings
Rebar Modelling & Detailing Services Project Title : Basalt Project - Fletcher ReinforcingClient : Fletcher Reinforcing Project Description : A 67000m2 sized GIB Production factory constructed at Tauranga. Silicon worked closely with Fletcher reinforcing Rebar modelling the concrete kettle wall, slab and foundation on Revit 3D. Location : Basalt Project - Fletcher Reinforcing New Zealand Click here to View Project Drawings
Rebar Modelling & Detailing
Project Title : Peacock BridgeClient : Downer NZ Project Description : A four-lane bridge constructing over the Waikato River passes to Hamilton. The concrete bridge has a span of 95-110m. Silicon is working closely with Downer NZ, rebar modelling and producing BBS in Revit. It includes clash detections and coordination.Location : New Zealand Click here to View Project Drawings
Rebar Modelling & Detailing Services Project Title : THE UNIVERSITY OF WAIKATO Client : Steel and Tube Project Description : The University of Waikato is an iconic educational institute located at Hillcrest, Hamilton. Silicon worked closely with Steel & Tube on rebar modelling & detailing the foundation, RC wall and RC columns. Location : New Zealand Click here to View Project Drawings
Rebar Detailing Services Project Title : Oceania Elmwood Client : Nauhria Reinforcing Project Description : Oceania Elmwood is an aged care and retirement Living Village. Silicon detailed the Rebar for foundation, columns, beams and slabs, produced the BBS sheets for construction. Location : New Zealand Click here to View Project Drawings
Precast Shop drawing Project Title: 787 - Highbrook Riverside Warehouse Client: Wilson Precast Project Description: 787 Highbrook Riverside is a warehouse constructed by Wilson precast. Silicon detailed the Precast stairs and provided the shop drawing for construction. Location: 787 - HIGHBROOK RIVERSIDE WAREHOUSE New Zealand Click here to View Project Drawings
Precast Shop Drawing Project Title : McLeod Green Client : Wilson Precast Project Description : McLeod Green is terraced housing development located at Te Atatu South. Silicon detailed the Precast walls and provided the shop drawing for construction. Location : New Zealand Click here to View Project Drawings
Precast Shop drawing Project Title: Porters Avenue Footbridge Client: Wilson Precast Project Description: Porter avenue footbridge is a CRL project worked alongside with Wilson precast. Silicon detailed the Precast reinforcement and provided the shop drawing for construction. Location: PORTERS AVENUE FOOTBRIDGENew Zealand Click here to View Project Drawings
Rebar Modelling & Detailing Services Project Title : Auckland International Airport Client : Complete Reinforcing Project Description : The Auckland International Airport is the largest and busiest airport in New Zealand. For the extension of the Airport, silicon worked closely with complete reinforcing in detailing the PT beams for this project. Location : New Zealand – Auckland Click here to View Project Drawings
Rebar Modelling & Detailing Service Project Title : Mangere Pumping Station Client : Steel and Tube Project Description : The Mangere Wastewater Treatment Plant is a significant facility in the region, responsible for treating much of Auckland's wastewater. Silicon worked closely with steel & Tube in modelling and detailing the Chamber shafts and Pipe supports. Location : New Zealand Click here to View Project Drawings
Precast Shop Drawing Project Title : Franklin Private HospitalClient : Span It Precast Project Description : Franklin Private Hospital is a 1100Sq.m project located at Pukekohe. Silicon worked closely with Span It Precast to detail the precast wall panels and produce shop drawings. Location : BASALT PROJECT - FLETCHER REINFORCING New Zealand Click here to View Project Drawings
Precast Shop Drawing
Project Title : waterloo stationClient : Fusion Civil Project Description : Waterloo Station is one of the underground metro stations of Sydney’s Metro City. Silicon worked closely with Fusion Civil in detailing the Precast wall panels and produce shop drawings.Location : Australia Click here to View Project Drawings
Precast Shop Drawing Project Title : Northern Beaches Client : Fusion Civil Project Description : Northern Beaches Hospital Road Connectivity and Network Enhancement is a development project by Transport for NSW. Silicon worked closely with Fusion Civil in detailing and preparing shop drawings of the Precast fascia and coping panel for the whole bridge. Location : Australia Click here to View Project Drawings
Precast Shop Drawing Project Title : Central Station Metro box Client : Waeger Constructions Ltd Project Description : The New South Wales (NSW) Government is actively constructing the Sydney Metro West, an innovative underground metro railway project. This initiative is designed to significantly increase the rail capacity connecting Greater Parramatta and the Sydney Central Business District (CBD). Silicon worked on detailed Precast wall panels from the intercity platform to Basement 3. Location : Australia Click here to View Project Drawings
Steel Fabrication Shop Drawings Project Title : New Zealand International Convention Center Limited Client : Fletchers Construction Company Project Description : The New Zealand International Convention Centre (NZICC) in Auckland is a significant venue of about 32500 Sq.m gross floor area which specifically designed to host large-scale conferences, conventions, and international events. Silicon worked closely with Fletcher construction, detailed and produced the external Carpentry-Roof Dura Panel Shop Drawings. Location : New Zealand Click here to View Project Drawings
Steel Fabrication Shop Drawings Project Title : KARORI CRESCENT,ORAKEI Client : Scott Building Ltd Project Description : Karori Crescent is an impressive luxury residence that spans approximately 496 square meters and features six bedrooms and four bathrooms. Silicon worked closely with Scott building to detail the steel columns, beams and roof fabrication shop drawings. Location : Orakei, Auckland 1071, New Zealand Click here to View Project Drawings
Steel Fabrication Shop Drawings Project Title : Jervoise ApartmentClient : Scott Building Ltd Project Description : In the heart of Auckland's prestigious Herne Bay, a boutique development of eight three-bedroom apartments stands as an iconic testament to thoughtful architecture and sophisticated design. This development stands as a sophisticated landmark, a true embodiment of architectural brilliance and refined living. Silicon detailed the structural steel fabrication shop drawings. Location : Auckland New Zealand Click here to View Project Drawings
Steel Fabrication Shop Drawings
Project Title : Westconnex M4-M5 TunnelsClient : Precise Way Pty Ltd Project Description : The WESTCONNEX M4-M5 Link Tunnels represent a monumental leap in Australia's infrastructure landscape; spanning an impressive 33 kilometres, this colossal road tunnel project stands as the largest of its kind in the country. Silicon detailed the structural steel framing and produced shop drawings for the same. Location : Australia Click here to View Project Drawings
Steel Fabrication Shop Drawings Project Title : Lachlan Bridge Client : S&L Steel Ltd Project Description : The Lachlan Bridge stands out with its bold and vibrant blue colour and span of 170m long, making it a visually striking landmark in addition to being a bustling and essential transportation link. Silicon worked on detailing the parametric structural steel design and produced the shop drawings. Location : Sydney Australia Click here to View Project Drawings
Steel Fabrication Shop Drawings Project Title : 3-5 West Street Client : Spartan Steel Project Description : 3-5 West Street is a thriving commercial hub featuring national retailers and businesses which is about 740sq.m total area. Silicon worked closely with Spartan Steel in detailing the structural steel framing and fabrication shop drawings. Location : North Sydney NSW 2060, Australia Click here to View Project Drawings
Steel Fabrication Shop Drawing Project Title : Narangba Client : Walz Group Project Description : Narangba reservoir is a 67.1m Dia tank. Silicon is working closely with the Walz group to deliver the detailing of the structural steel roof and to produce shop drawings. Location : Australia Click here to View Project Drawings
  • Precast Shop Drawing

  • Project Title : Larrakia Cultural Centre, Sunbuilt Pty ltd Australia
  • Client : -
  • Project Description : Silicon detailed the precast walls, Beam and deck slab and provided the shop drawing for construction.
  • Location : Australia

  • Click here to View Project Drawings
Rebar Shop Drawing
Project Title : Western springs steel for permanent Shaft lining lift New ZealandClient : -Project Description : Silicon Provided the rebar shop drawing and Bar bending schedule.Location : New Zealand
 Click here to View Project Drawings
